Epson TM T88V Technical Reference Guide

Chapter 1 Product Overview
13
1
Product Overview
This chapter describes features and specifications of the product.
Features
Printing
•High speed printing (300 mm/s maximum).
•Shifting from 80 mm width paper printing to 58 mm width paper printing is available.
•Multi-tone graphic printing.
Handling
•Easy drop-in paper loading
Software
•Command protocol is based on the ESC/POS Proprietary Command System.
• OPOS ADK, OPOS ADK for .NET, JavaPOS ADK, and Windows printer drivers are available.
•In addition to supporting several kinds of bar code printing, DS1 DataBar printing and two-
dimensional symbol (PDF417, QR code, MaxiCode, Composite Symbology) printing are
possible.
•Various layouts are possible by using page mode.
•A maintenance counter fun
ction is supported.
•User-defined font function is supported.
• Paper-saving function is supported.
•Image tone can be changed.
•The remote configuration tool allows you to check the status of and configure the printer con-
nected to a computer on the
network.
•The TM-T88V is ENERGY STAR qualified. (Some configurations may be exempted, depend-
ing on their components.)

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
