70
Attaching the Connector Cover
When using the connector cover, attach the connector cover.
Follow the steps below to attach the connector cover to protect cables.
1
Turn over the printer.
2
Position the two hooks on both sides of the connector cover so that they
hook the printer case.
3
Push the connector cover down to click onto the printer case.
4
Pass each cable through the cable exits at the bottom of the connector
cover.
5
Turn over the printer and make sure the cables are not pinched.
Hooks
To Next Page
