Epson TM T88V Technical Reference Guide

88
Memory Switch Setting Mode
You can configure the memory switches (customized values) of the printer.
•Print density
•Communication conditions using a serial interface
•Auto reduction of the amount of paper to use
•Autocutting of paper while the cover is closed
•Paper width
•Default value of character code page/interna
tional character set
•Auto replacement of font
•Selection of an interface
•Selection of USB class
•Power supply capacity
Follow the steps below to run this mode.
1
Close the roll paper cover.
2
Turn on the printer while pressing the Feed button.
The printer prints current status of the printer.
3
After the printing has been completed, press the Feed button for more
than one second.
The printer starts printing instructions.
4
After the printing has been completed, press the Feed button three
times.
5
Then press the Feed button for more than one second.
The printer starts printing instructions.
After one setting has been completed, the printer stores the setting and then starts initializing.
After that, the printer returns to the normal mode.
For detailed information about memory switches (customized value), see "Setting the Mem-
ory Switches (Customized Value)" on page 48.

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
