Epson TM T88V Technical Reference Guide

24
Product Specifications
Printing method Thermal line printing
Cutting method Partial cut (cutting with one point in left edge left uncut)
Roll paper (single-ply) width 80 mm width paper printing: 79.5 ± 0.5 mm (3.13 ± 0.02")
58 mm width paper printing: 57.5 ± 0.5 mm (2.26 ± 0.02")
Interfaces Serial (RS-232), Parallel (IEEE1284), Ethernet (10/100BASE-T),
USB (Full-speed), Wireless LAN (IEEE802.11b)
Buffers Receive buffer 4 KB/45 bytes (selectable using DIP switch 1-2)
Downloaded buffer 12 KB (both for user-defined characters and downloaded
images)
NV graphics data 256 KB
Barcode/two-dimensional symbol/
composite symbol printing
UPC-A, UPC-E, JAN 8 (EAN 8), JAN 13 (EAN 13),
CODE 39, ITF, CODABAR (NW-7), CODE 93,
CODE 128, GS1-128,
GS1 DataBar Omnidirectional, GS1 DataBar Truncated,
GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional,
GS1 DataBar Limited, GS1 DataBar Expanded,
GS1 DataBar Expanded Stacked,
PDF417, QR CODE, MaxiCode,
Composite Symbology
DKD function 2 drives
Supplied voltage DC 24 V ± 7%
Life Mechanism 20,000,000 lines
Thermal head 150 million pulses
150 km
Autocutter 2,000,000 cuts (when using the specified original paper types,
PD150R or PD160R)
1,500,000 cuts (when using paper types other than the
specified original paper types)
MTBF 360,000 hours
MCBF 70,000,000 lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions 145 × 195 × 148 mm {5.71 × 7.68 × 5.83"} (W × D × H)
Weight (mass) Approx. 1.6 kg {3.5 lb} (roll paper excluded)

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
