54
Chapter 3 Advanced Usage
DIP Switch Bank 2
Selecting the Print Density (DIP Switches 2-3/2-4)
SW Function ON OFF
Default
setting
2-1 Handshaking (BUSY condition) Receive buffer full
Offline
OFF
Receive buffer full
2-2 Reserved (Do not change setting) Fixed to OFF OFF
2-3
Selects print density
See the " Selecting the Print Density (DIP Switches 2-3/2-
4)" table below.
OFF
2-4
2-5
Reserved (Do not change setting) Fixed to OFF OFF
2-6 Reserved (Do not change setting) Fixed to OFF OFF
2-7 I/F pin 6 reset signal Enabled Disabled OFF
2-8 IF pin 25 reset signal Enabled Disabled OFF
• For DIP Switch 2-1 (BUSY condition), see also "Selecting the BUSY Status" on page 58.
• When y
ou use the APD, change the setting of DIP switch 2-1 (BUSY condition) to ON.
Function SW 2-3 SW 2-4
Do not set ON ON
Print density (standard) OFF OFF
Print density (medium) ON OFF
Print density (dark) OFF ON
• If the print density is set to “Medium” or “Dark” level, print speed may be reduced.
• The print density can be set with DIP switches (2-3/2-4) or the software settings. (See "Software
Se
ttings" on page 59.)
