Epson TM-U950 User Manual

1-20 Setting Up the Printer
Running the self test with slip paper
Note:
Be sure to install both paper rolls to prevent slip paper jams.
1. Make sure the printer is turned off and the printer cover is
closed properly.
2. While holding down the
JOURNAL/SLIP FEED
button, turn on
the printer to begin the self test. (The
SLIP
light blinks.)
3. Feed a sheet of slip paper into the printer. The printer loads the
paper automatically, prints the printer settings, and then ejects
the paper. (The SLIP light blinks.)
4. Remove the paper from the printer and feed another sheet of
slip paper into the printer to print characters from the character
table. Continue to feed slip paper into the printer until the self
test prints the following:
***completed***
The printer is ready to receive data as soon as it completes the self
test.
Note:
If you want to pause the self test manually, press the
JOURNAL/SLIP FEED button. Press the JOURNAL/SLIP
FEED button to continue the self test.
Setting the DIP Switches
CAUTION:
Turn off the printer while removing the DIP switch cover to
prevent an electric short, which can damage the printer.

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
