Epson TM-U950 User Manual

4-10 Reference Information
❏
Since the slip ejection detector uses a reflective photo detector,
paper that has holes or dark portions with low reflection (less
than 40% reflection) at the detector position must not be used.
(See the illustration below.)
❏
Be sure to perform slip printing with both paper rolls loaded to
avoid paper jams.
❏
Use thinner paper (N30 or equivalent) between the top and
bottom sheets of multi-ply paper. If thick paper is used, the
copy capability is lowered.
Sub-slip feed
roller position
Form stopper
position
14.6mm
(.58")
3mm (.12")
2mm (.08")
Slip insertion
sensor position
Paper feed direction
10mm
(.39")
Make sure there are
no holes and low reflection
in this area of the paper

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
