Epson TM-U950 User Manual

4-6 Reference Information
Paper Specifications
Paper feed method:
Friction feed
Paper feed pitch:
Default 1/6 inch
Can be set in units of 1/144 inch by the
ESC 3
and
ESC J
commands.
Paper feed speed:
Approx. 60.3 ms/line (1/6 inch
feeding)
Approx. 3.4 inches/second
(continuous feeding)
Paper size and weight: Paper roll (single-ply)
Size: Width 69.5 mm ± 0.5 mm
(2.74" ± 0.02")
Maximum
outside dia:
83 mm (3.27")
Thickness: 0.06 to 0.09 mm (.0024 to
.0035")
Weight: 52.3 to 64.0 g/m
2
(13.9 to
17 lbs) (JIS P8124) (45 to
55 Kg (20.41 to 24.94 lbs)/
1000 sheets/788 mm
✕
1091mm (31.02"
✕
42.95")
Paper roll
inside
diameter:
10 mm (0.39") or more

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
