Epson TM-U950 User Manual

1-26 Setting Up the Printer
Adjusting the Paper Near End Detectors
The paper near end detectors detect when the paper is almost gone
by measuring the diameter of the paper roll. Software programs
can use the
ESC c 4
command to stop printing when the paper is
almost gone.
If you want to change the amount of paper remaining when the
printer stops printing, follow the steps below to adjust either paper
near end detector.
Note:
The printer also has two paper end-sensors that stop the printer at
the very end of a roll. These sensors cannot be turned off by software.
1. Open the printer cover and remove the paper roll.
2. Determine the point on the paper roll at which you want the
paper roll end detection to be triggered. Then measure the
distance A shown in the illustration.
Note:
There may be some difference between the measured distance A and
the actual sensing position.
distance A

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
