166
SECTION 5 MAINTENANCE
5. Slide the handle forward and thread it rmly onto the torch body.
4. To install the new torch head assembly - Connect the pilot arc cable and the main power cable by reversing
the steps taken to disconnect them. Be sure the gas and water ttings are tight enough to prevent leaks, but
do not use any kind of sealant on them. If the knife connection seems loose, tighten the connection by press-
ing on the parts with needle-nosed pliers after they are assembled. Secure the gray pilot arc insulator with 10
turns of electrical tape.
New Torch Head Assembly
