2.2 Scope
The purpose of this manual is to provide the operator with all the information required to install and service
the PT-36 Mechanized Plasmarc Cutting Torch. Technical reference material is also provided to assist in trouble-
shooting the cutting package.
2.3 Package Options Available
PT-36 package options available through your ESAB dealer. See Replacement Parts section for component part
numbers.
2.1 General
The PT-36 Mechanized Plasmarc Cutting Torch is a plasma arc torch factory assembled to provide torch compo-
nent concentricity and consistent cutting accuracy. For this reason, the torch body can not be rebuilt in the eld.
Only the torch front-end has replaceable parts.
SECTION 2 DESCRIPTION
DESCRIPTIONS FOR PT-36 TORCH ASSEMBLY'S PART NUMBER
PT-36 TORCH AY 4.5 ft (1,3m) 0558003849
PT-36 TORCH AY 6 ft (1,8m) 0558003850
PT-36 TORCH AY 12 ft (3,7m) 0558003852
PT-36 TORCH AY 15 ft (4,6m) 0558003853
PT-36 TORCH AY 17 ft (5,2m) 0558003854
PT-36 TORCH AY 25 ft (7,6m) 0558003856
PT-36 TORCH AY 14 ft MINI-BEVEL (4,3m) 0558005741
