HARDWARE NEEDED (ACTUAL SIZE)
HEX NUT M10-1.5, WITH CAP
2B-6799-00
21
(QTY. 2)
WASHER _ CURVED M10
2B-6802-00
39
(QTY. 2)
16. Secure pole with hardware shown. Finger Tighten only.
39
21
20
HEX HEAD BOLT M10-1.5 X 100mm
1B-7078-00
20
(QTY. 2)
MAKE SURE HEADS OF THE
BOLTS ARE INSERTED INTO
THE CUT OUT OF THE POLE.
NOTE
NOTE
FINGER TIGHTEN ONLY!
