ESCALADE SilverBack NXT50 - Page 6

6
Wheel Assembly (Parts pre-assembled to wheel)
BALLAST CAP
3M-8996-00
BALLAST CAP WASHER
3M-8999-00
REINFORCEMENT PLATE
8S-7711-20
POLE CAP
3M-8997-00
BUSHING, BOARD ARM
3M-8994-00
AXLE BUSHING
3M-9003-00
Wheel Hub, Outside
3M-9001-00
Wheel Hub, Inside
3M-9002-00
SPRING
5V-6041-00
BACKBOARD BOX
1A-7905-20
ACTUATOR GRIP
3M-9034-00
ACTUATOR LOCK ASSEMBLY
4A-8141-20
38
14
40
31
26
13
37
55
25
5
8
6
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 2)
(QTY. 2)
(QTY. 2)
(QTY. 4)
P A R T S L I S T ( N O T A C T U A L S I Z E )
Wheel
3M-8992-00
7
(QTY. 2)
WHEEL PLUG
3M-9004-00
41
(QTY. 2)
42
O-RING
3M-8998-00
(QTY. 2)
(Pre-assembled to
Wheel Plug)
(Pre-assembled to
Ballast Cap)
Wheel Plug Key
3M-9022-00
(QTY. 1)
57
(Pre-assembled to
Top Pole)
(3/8” Allen Wrench
can be substituted
for Wheel plug key)
(Pre-assembled to
Ballast)
