ESCALADE SilverBack NXT50 - Page 5

5
LOWER BOARD ARM
8S-7713-20
UPPER BOARD ARM
8S-7712-20
AXLE
8S-7710-20
AXLE ROD
1B-7140-00
BRACE TUBE, RH
8S-7708-20
BRACE TUBE, LH
8S-7709-20
52
49
19
18
9
4
ACTUATOR BAR
1A-7920-20
(QTY. 1)
(QTY. 2)
(QTY. 2)
(QTY. 1)
(QTY. 1)
(QTY. 1)
(QTY. 1)
P A R T S L I S T ( N O T A C T U A L S I Z E )
BOARD ARM CAP
3M-9017-00
56
(QTY. 6)
(Pre-assembled to
Board Arms)
53
(Actuator Bar Cap
Pre-installed)
(Has a sticker on it)green
(Has a sticker on it)red
(Packed inside of
Top Pole)
green sticker
on here
red sticker
on here
