The edger calculates the shelf bevel value to be applied between each of the four or eight points of
each area.
The bevel trajectory on the rear surface is modified in the work screen. The result can be viewed in
the zoom window.
Press to perform a back chamfer of the assembly aid.
The chamfer is selected .
The result can be viewed in the zoom window.
Press the “cycle start” button (front face) or .
The edging cycle starts.
When the edging cycle is finished, the retouch screen is displayed.
Press to release the lens.
If necessary, retouch the lens.
Otherwise, start edging the second lens. Select the lens directly on the screen, on the left or right of the
work area.
The edging screen for the second lens is displayed. All finishes chosen and the modifications made
are kept.
