◦ Front surface tracking: the crest of the bevel or the middle of the groove is positioned at a
constant distance from the front surface.
◦ Distributed mixed finish: the crest of the bevel or the middle of the groove is positioned in
proportion to the thickness of the lens, with respect to the front surface.
2. Access to the area defining screen
Access on a 1:1 scale.
3. Cursor movement
The cursor is represented by the green square along the shape. To move it, select it directly or use the
and buttons.
4. Settings for area 1
◦ Bevel finish
◦ Groove finish
◦ Flat-edge finish
5. Zoom window
Display of the distance from the edges of the lens to the position of the cursor.
6. Position of the center of the groove or bevel
Value expressed in mm ('Front surface tracking' mode) or in % ('Distributed mixed finish' mode).
7. Settings for area 2
◦ Bevel finish
◦ Groove finish
◦ Flat-edge finish
8. Navigation
◦ Stop the cycle
◦ Return to the main edging screen without saving your changes
◦ Start the edging cycle
Area definition screen
