ES720.1 - User’s Guide 17
ETAS Hardware Description
3.2 Housing
3.2.1 Properties
A housing with connections at the front and rear side of the device is used for
the ES720.1. The robust metal housing of the ES720.1 is equipped with non-skid
plastic feet.
To secure it in a vehicle or the lab, it can be bolted onto a support system without
any effort. The housings of this device family can also be connected with each
other, quickly and easily (see chapter
5.1 on page 35).
The ES720.1 module is designed for use in the lab, on the test bench and in the
passenger cell of motor vehicles.
3.2.2 MAC Address of the Ethernet Adapter
The MAC address of the Ethernet adapter is located on the bottom panel of the
device. This address is required for the software licensing.
3.2.3 MAC Address of the WLAN Adapter (Drive Recorder with WLAN Module)
The MAC address of the WLAN adapter is located on the bottom panel of the
devices that are equipped with an internal WLAN module.
