ES720.1 - User’s Guide78
Cable and Accessoires ETAS
9.2 ETH Interface Cable
9.2.1 CBE100 Cable
Side A Side B
Fig. 9-3 CBE100-x Cable
Order Name Short name Order 
Number
Ethernet PC Connection Cable, Lemo 1B
FG
G - RJ45 (8mc-8mc), 3 m
CBE100-3 F 00K 102 559
Ethernet PC Connection Cable, Lemo 1B
FG
G - RJ45 (8mc-8mc), 8 m
CBE100-8 F 00K 102 571
9.2.2 CBE130 Cable
Side A Side B
Fig. 9-4 CBE130-x Cable
Order Name Short name Order 
Number
Ethernet Connection a
nd Power Supply
Cable, Lemo 1B FGF Lemo 1B FGD (8mc-
8mc), 0m45
CBE130-0m45 F 00K 102 748
Ethernet Connection a
nd Power Supply
Cable, Lemo 1B FGF Lemo 1B FGD (8mc-
8mc), 3 m
CBE130-3 F 00K 102 587
