ES720.1 - User’s Guide30
Description of Functions ETAS
Available "Wake-Up" Events
Event Description
No. in
Fig. 4-2
Abbrevia-
tion
2 PBP Briefly pressing the "Power" button on the module
3 On Pin External "Power" remote button or
trigger event at dig-
ital input ("PSCI" pin, "I/O" port), Low to High
4 On Time Start at a specific point in time (configurable timer)
5 On ETH Communication at the "ETH" interface (PC or measur-
ing module)
Available "Shutdown" Events
Event Description
No. in
Fig. 4-2
Abbrevia-
tion
6 PBP Pressing the "Power" button on the module
PBPE Pressing the "Power" button on the module for more
th
an five seconds ("Emergency-Off")
7 On Pin External "Power" remote button or
trigger event at dig-
ital input ("PSCI" pin, "I/O" port), High to Low
9 On Time End at a specific point in time (configurable timer)
8 Auto Measurement finished, no additional tasks
10 Timer Change from "Fast Boot Standby" to "Low Power
Sta
ndby" after timer is expired
Available Timers
Configurable timers allow delaying events that are intended to trigger a change
of the operating state of the ES720.1. If necessary, a new hibernation file is being
created.
Shutdown/Standby Delay Timer: The counter can be used to define the
tim
e period in the configuration program by which all events that are intended
to trigger a change of the operating state of the ES720.1 are delayed. Pressing
the "Power" button on the module and specific events of the INCA experiment
are not affected or delayed by this timer.
Fast Boot to Shutdown Timer: The counter can be used to define the time
p
eriod in the configuration program after whose expiration the ES720.1 changes
from the operating state "Fast Boot Standby" to the operating state "Low Power
Standby". This counter is activated when changing to the operating state "Fast
Boot Standby".
