ES720.1 - User’s Guide 73
ETAS Technical Data
23 LED_ERR Output 5 V Status corresponds to the status of the LED ER,
d
Low Current LEDs to ground
24 LED_MEM Output 5 V Status corresponds to the status of the LED ME
M
ing Low Current LEDs to ground
5 GND - - - Ground
6 GND - - - Ground
Pin Signal Type Logic I max.
[mA]
Meaning
