138 Eos Family Operations Manual
Label
System
Rack
Lug
Module Type
Firing Mode
Control Mode
Curve
Recorded Loads
Note: The System ID number from CEM3 is not currently supported.
Note: Rack numbers and dimmer numbers need to be unique for Eos to properly recognize
them. For CEM+, dimmers also need to be patched to different sACN addresses.
With a dimmer or dimmers selected, you can edit various dimmer settings in the property view,
which will display in the CIA. Items with a caret (>) are editable. When multiple dimmers are selected
together for editing, an “*” will show for data that is different between the selected dimmers.
FDX dimmers will not display data for the following:
Recorded Load
Actual Load
Rack Dimmer Source
Threshold
Scale Minimum
Preheat Enable
Preheat Timing
AF Enable
