Patch 147
4. Press {New} to add ranges. Repeat this step until you have as many slots as are required by the
number determined in step 3.
5. Use the [Page] keys to select the range and field you wish to edit. Fields are:
DMX Min - enter the minimum value (0 through 255) for the range slot you are defin-
ing.
DMX Max- enter the maximum value (0 through 255) for the range slot.
User Min - enter the value that will be displayed to users (for example, what will be dis-
played in the live summary view) when the slot is at its minimum value. Value can range
from -32767 to 65535.
User Max- enter the value that will be displayed to users when the slot is at its max-
imum value. Value can range from -32767 to 65535.
6. Press {Label} to add a label to any range slots. These will appear in the encoder LCD when the
related parameter is displayed for the new fixture.
7. Press {Return} when you have finished editing the ranges.
To delete a range value, select it and press {Delete}.
Lamp Controls
For many devices, their lamp and motor control functions can be controlled remotely using DMX.
These will often require use of a timed sequence of DMX levels to control various functions such as
striking the lamp, resetting the fixture, and other specific actions.
To definethelamp controls for adevice:
1. With the fixture selected, press {Lamp Ctrls}. The lamp control display will open.
2. Press {New} to add as many lamp control options as needed.
3. Click on the name in the lamp control column to name it.
4. Click in the Steps columns (Time, DMX, and Level).
5. Press {New} to add as many steps needed for the lamp control.
6. Select the time column to change the timing for each step. Timing is in seconds. The standard
time in the Eos Family library is 12 seconds.
Note: It is not recommended that you set the time to {Hold} unless the DMX value
should permanently remain at that level. In order to alter a level set with a time of
{Hold}, another lamp control to change that DMX value would need to be created.
7. For each step created, click in the DMXcolumn and press {New} to add as many DMX
addresses and levels as needed. You may setup as many levels as needed for each step.
Snap Parameters
Certain parameters may not want to be subjected to cue timing. Those parameters can be set to
snap. By default, Eos will snap the parameters listed in the following table:
Beam FX
Index/Speed
Effect Library MSpeed Shutter
Camera IR Image Enable Negative Shutter Strobe
Clip Directory File Object Directory Strobe Mechanism
Color Effect File Type Object File Sync Source
Color Index
Front/Rear Pro-
jection
Output Command Text
