Chapter 7 Setup
> 7.4 Monitoring Setup
ETERNUS DX60/DX80/DX90 Disk storage system User Guide
173
Copyright 2010 FUJITSU LIMITED
P3AM-3042-07ENZ0
3 Set the necessary items in the [Notification E-Mail] area.
• Select "Enable" in "Notification E-Mail".
• Specify the E-mail destination address in "Destination E-Mail Address".
Figure 7.34 [Setup E-Mail Notification] screen (Notification E-Mail)
4 Click the "Mail Server Settings" link.
The [Mail Server Settings] screen appears.
5 Set the necessary items in the [Mail Server Settings] area.
Figure 7.35 [Setup E-Mail Notification] screen (Mail Server Settings)
6 After finishing the necessary settings, click the [Set] button.
A confirmation screen appears.
7 Click the [OK] button.
The specified send E-mail setting is registered.
