2.5 AC Outlet Box
There are two sizes of AC outlet box: 1U and 2U.
2.5.1 AC Outlet Box (1U)
1U AC outlet box has four outlets and two inlets.
Figure 2.33 AC outlet box (1U)
2.5.2 AC Outlet Box (2U)
2U AC outlet box has twelve outlets and two inlets.
Figure 2.34 AC outlet box (2U)
I
MPORTAN
T
• Each enclosure has two power supply units (PSU#0 and PSU#1). The
power cords must be connected to the inlets of both power supply units.
• When connecting the power cord right after it is disconnected, wait for
the STATUS LED of the power supply unit is turned off completely (about
10 seconds) before connecting it again.
Inlet (INPUT)
Power supply code (AC Input cable)
connects here.
Outlet (OUTPUT)
Power supply code (AC output cable)
connects here.
Main line switch
Inlet
Power cords (AC Input cable
are connected here.
Outlet (OUTPUT)
Power cords (AC output cable)
are connected here.
Main line switch
