118
13.4 THROTTLE HOUSING
DISASSEMBLY
Loosen the screws on the throttle housing cover.
Remove throttle housing cover and gasket.
Disconnect throttle cable from the throttle arm
and remove from the throttle housing.
NOTE:
Assembly is in the reverse order of disassembly.
13.5 STEERING SYSTEM
Removal of Kingpin and Tie-rod
Remove the front wheels and hub assy.
Remove the four self-lock nuts from the tie-rod ball joints
and take off the two tie-rods.
Screws
Tie-rod Bolts
Bolts
