145

After loosen these three screws, users can find a connector.

Please disjoin the connector in order to replace an electrical

bulb conveniently and safely. The steps show on pictures.

Installation is in the reverse order of disassembly.

Front Direction lights remove

To replace the direction lights must loosen the screws

as shown in picture.

Screws
