Eton VECTOR ST 250 - Alternator;Starting Clutch Diagram; ACG & Start One Way Clutch

84
10. ALTERNATOR/STARTING CLUTCH
10-1 Mechanism Diagram
10-2 Precautions in Operation
10-3 Right Crankcase Cover Removal
10-4 A.C.G. Set Removal
10-5 Right Cover Bearing
10-6 Flywheel Removal
10-7 Starting Clutch
10-8 Flywheel Installation
10-9 A.C.G. Set Installation
10-10 Right Crankcase Cover Installation
10-1 Mechanism Diagram
5.0~6.0kgf-m
1.0~1.4kgf-m
0.8~1.2kgf-m
