3. MECHANICAL ASSEMBLY

3.1 BEFORE STARTING

Read this manual carefully before installing the system.

Inparticular,thesafetyinstructions,electricalrequirementsandcurrentregulationsforthemachineortheprocessinwhich

this device is involved must be observed. The use and application of the information contained herein require experience in the

designandprogrammingofautomatedcontrolsystems.Onlytheuser,systemintegratorormachinebuildercanbeawareofall

theconditionsandfactorspresentduringtheinstallation,configuration,operationandmaintenanceofthemachineorprocess,

andcanthereforedeterminetheassociatedautomationequipmentandtherelatedsafetiesandinterlockswhichcanbe

effectively and properly used. When selecting automation and control equipment and any other related equipment or software

foraparticularapplication,alwaysconsideralltheapplicablelocal,regionalornationalstandardsand/orregulations.

WARNING

REGULATORY NON-COMPLIANCE

Makesurealltheequipmentusedandthesystemscomplywithalltheapplicablelocal,regionalandnationalregulations.

3.2 INFORMATION ON INSTALLATION AND THE ENVIRONMENT

Beforecarryingoutanyworkontheequipment,readtheseinstructionscarefully,makingsureyouunderstandeverything.

DANGER

RISK OF ELECTRIC SHOCK, EXPLOSION OR ELECTRIC ARC

• Only use electrically insulated measuring devices and equipment.

• Do not install the equipment while the power supply is connected.

• Switchoffallequipment,includingconnecteddevices,beforeinstallingoruninstallingthedevice.

• Alwaysuseacorrectlycalibratedvoltmetertocheckthesystemisswitchedoff.

• Do not touch the unshielded components or the terminals while they are live.

• Donotopen,disassemble,repairormodifytheproduct.

• Do not expose the equipment to liquids or chemicals.

• Before applying voltage to the equipment:

• Makesureallprotectiveelements,suchascovers,hatchesandgrilles,arefittedand/orclosed.

• Checkallwiringconnections.

Thisdevicewasdesignedtooperateinnon-hazardousenvironments,excludingapplicationsthatgenerate,orcouldpotentially

generate,hazardousatmospheres.Onlyinstallthisdeviceinareasandforapplicationswhicharereliablyfreefromhazardous

atmospheres.

DANGER

RISK OF EXPLOSION

• Only install and use this deviceinsitesthatarenotatrisk.

• Donotinstallorusethisdeviceinapplicationswhicharecapableofgeneratinghazardousatmospheres,suchas

applications that use flammable refrigerants.
