Par. Description MU Range Default
A2
Type of low temperature alarm.
0 = Disabled; 1 = Relative to SET; 2=Absolute.
--- 0...2 2
A4 High temperature alarm threshold. °C/°F -99.0...99.0 10.0
A5
Type of high temperature alarm.
0 = Disabled; 1 = Relative to SET; 2=Absolute.
--- 0...2 2
A6
Delay in activation of temperature and humidity alarms due to threshold exceeded when
device is switched on.
min 0...99*10 12
A7 Minimum and maximum temperature alarm delay. min 0...240 15
A8
Delay in activation of alarm due to threshold exceeded after defrost.
min 0...240 15
A9
Delay in activation of alarm due to threshold exceeded after door closed.
min 0...240 15
A10 Duration of power failure to record alarm. min 0...240 15
A11 Hysteresis referring to A1 and A4 to determine alarm reset threshold. °C/°F 1.0...15.0 2.0
EVAPORATOR/CONDENSER FANS Group
F0
Evaporator fan mode in normal operating mode.
With F0 = 0 it is possible to manage cycles by setting F11,F12.
0 = In cycles; 1=AlwaysON;
2 = On with compressor ON;
3 = Thermostat controlled (F1 relative to temperature control);
4 = Thermostat controlled with compressor ON (F1 relative to temperature control).
--- 0...4 1
F1 Evaporator fan regulation threshold with F0=3,4. °C/°F -99.0...99.0 -4.0
F2
Evaporator fan mode during defrost.
0=OFF;1 = ON; 2=AccordingtoF0.
--- 0...2 0
F3 Maximum time evaporator fans off after dripping. min 0...15 0
F4 TimeevaporatorfansOFFinenergysaving. s 0...240*10 0
F5 Time evaporator fans ON in energy saving. s 0...240*10 10
F7 Evaporator fans ON threshold from dripping. °C/°F -99.0...99.0 5.0
F9 Evaporator fan switch-off delay from compressor switch-off s 0...240 5
F11 Condenser fans ON threshold. °C/°F -99.0...99.0 15.0
F12 CondenserfansOFFdelayfromcompressorOFF. s 0...240 30
F15 TimeevaporatorfansOFFwithcompressorOFF. s 0...240 0
F16 TimeevaporatorfansONwithcompressorOFF. s 0...240 1
DIGITAL INPUT PROPERTIES Group
i0
Digital input ID1 function.
0 = Disabled;
1=Compressor+evaporatorfansOFF;
2=EvaporatorfansOFF;
3=LightON;
4=Compressor+evaporatorfansOFF,lightON;
5=EvaporatorfansOFF,lightON.
--- 0...5 5
i1
Digital input ID1 activation (polarity).
0 = Contact closed (NC); 1 = Contact open (NO).
--- 0/1 0
i2 Delay in alarm signal from door open. -1 = Disabled. min -1...120 30
i3 Maximum time for inhibiting regulation with door open. -1 = Disabled. min -1...120 15
i5
Digital input ID3 function.
0 = Disabled;
1 = Energy saving;
2=iAalarm;
3=AUXON;
4 = Stand-by;
5 = Cth alarm;
6 = th alarm.
--- 0...6 0
i6
Digital input ID3 activation (polarity).
0 = Contact closed (NC); 1 = Contact open (NO).
--- 0/1 0
i7 Delay in alarm signal from door open. -1 = Disabled. min -1...120 0
i10 Door closed consecutive time for energy saving. min 0...999 0
i13 Number of door openings for defrost. 0 = Disabled. num 0...240 180
i14 Door open consecutive time for defrost. 0 = Disabled. min 0...240 32
