EVCO S.p.A.
EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 13 of 100
31
if present, K5 digital output (can be set through a configuration parameter to demister heating elements, auxiliary, alarms,
door resistors, neutral area operation resistors, condenser fan, compressor 2, defrosting 2, evaporator fan 2, pump down
valve, on/stand-by or man in cold room; manufacturer default is condenser fan).
32 if present, digital output 4 (room light)
33 seal
34 drilling lead for wall installation
35 ground terminal
36 raised profile
37 seal
For additional information, please refer to the following chapters.
