11.3 “Service” writing mode
11.3.1 Preliminary information
The device writes into the CSV file the following information:
- the value of the temperature detected by all the probes
- the value of the superheating (if available)
- the percentage the electronic expansion valve is open (if available).
Parameter Sd1 sets the writing interval; parameter Sd2 sets the duration of the writing mode.
The device also writes into the CSV file information about the following events:
- alarms activation/deactivation
- errors activation/deactivation
- device switching on/off
- defrost activation/end
- function “energy saving” activation/deactivation
- probes activation/deactivation
- loads switching on/off
- power supply restoring.
When these events arise the device records the value of the temperature detected by all the probes.
For each information the device records the time it has been recorded.
The following drawing shows the aspect of a file written with the “service” writing mode.
