EVCO S.p.A. EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 47 of 100
P7 0 100 % 50 50 50 50 50 50 50 50
percentage of the temperature detected by the inlet air
for the calculation of the CPT temperature (only ifP4 = 4)
(3)
P8 0 250 s/10 5 5 5 5 5 5 5 5 delay displaying temperature variation
P9 -99.9 99.9
bar g /
PSI g
not
avail.
not
avail.
not
avail.
not
avail.
not
avail.
not
avail.
-0.5 -0.5 pressure transducer minimum setting
P10 -99.9 99.9
bar g /
PSI g
not
avail.
not
avail.
not
avail.
not
avail.
not
avail.
not
avail.
7.0 7.0 pressure transducer maximum setting
PARAM. MIN. MAX. M.U.
EVB1204 EVB1214 EVB1206 EVB1216 EVB1226 EVB1236 EVB1246 EVB1256
MAIN REGULATOR
r0 0,1 (5) 15.0 °C/°F (1) 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
if u1 and/or u11 7, working set-point differential; see
also r12 (6)
if u1 and/or u11 = 7, proportional band; see also r12 (7)
r1 -99.0 r2 °C/°F (1) -50.0 -50.0 -50.0 -50.0 -50.0 -50.0 -50.0 -50.0 minimum working set-point
r2 r1 99.0 °C/°F (1) 50.0 50.0 50.0 50.0 50.0 50.0 50.0 50.0 maximum working set-point
r3 0 1 - - - - 0 0 0 0 0 0 0 0
locking of working set-point setting (using the procedure
described in paragraph”Setting the working set point”)
1 = YES
