EVCO S.p.A.
EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 6 of 100
room light 16 A 16 A 16 A 16 A 16 A 16 A
load 4 (default to room light) (3) 8 A 8 A
load 5 (default to condenser fan) (4) 8 A 8 A 8 A 8 A 8 A 8 A
load 6 (default to alarm ) (4) 8 A 8 A 8 A 8 A 8 A 8 A
Communication ports
RS-485 MODBUS for other EVCO products • • • • • • • •
Other characteristics
clock • • • •
alarm buzzer • • • • • • • •
three-phase defrost elements management • •
data logging extension for EN 12830 standard compliance • • •
integrated driver for unipolar stepper electronic expansion valves. • •
operation at low and high relative humidity percentages • • • • • • • •
overheated condenser alarm management • • • • • • • •
defrosting adaptive management • • • • • • • •
"HACCP" function • • • •
"energy saving" function • • • • • • • •
"rapid cooling" function • • • • • • • •
Notes
(1)
can be set through a configuration parameter to condenser temperature, critical temperature, evaporator 2 temperature or
CPT temperature parameter
(2) only available in the models with data logging for EN 12830 standard compliance
(3)
can be set through a configuration parameter to room light, demister heating elements, auxiliary, alarms, door resistors,
neutral area operation resistors, condenser fan, compressor 2, defrosting 2 evaporator fan 2, pump down valve, on/stand-
by or man in cold room
(4)
can be set through a configuration parameter to demister heating elements, auxiliary, alarms, door resistors, neutral area
operation resistors, condenser fan, compressor 2, defrosting 2 evaporator fan 2, pump down valve, on/stand-by or man in
cold room.
Available options
In some models, there is a magneto-thermal switch or differential magneto-thermal circuit breaker.
