EVCO S.p.A.
EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 67 of 100
i5 0 9 - - - - 7 7 7 7 7 7 7 7
6
=
ACTIVATION OF THE MINIMUM PRESSURE
SWITCH ALARM - the compressor will be switched
off, the display will show the flashing code “LP”
and the buzzer will be activated (until the input is
deactivated); if u1 and/or u11 = 10, the
compressor will be switched off after the pump
down valve has switched off (also look at C14 and
i17)
7
=
COMPRESSOR THERMAL PROTECTION - the
compressor will be switched off, the display will
show the flashing code “C1t” and the buzzer will
be activated (until the input is deactivated)
8
=
COMPRESSOR 2 THERMAL PROTECTION - the
compressor 2 will be switched off (only if u1
and/or u11 = 7), the display will show the flashing
code “C2t” and the buzzer will be activated (until
the input is deactivated)
9
=
MAN IN COLD ROOM ALARM ACTIVATION - the
man in cold room output shall be turned on (only
if u1 and/or u11 = 12), the display will show the
flashing code “MiC” and the buzzer will be
activated (until the input is deactivated)
i6 0 1 - - - - 0 0 0 0 0 0 0 0
type of multifunction input contact
0
=
normally open (active input with closed contact)
1
=
normally closed (active input with open contact)
i7 0 120 min 0 0 0 0 0 0 0 0
if i5 and/or i15 = 2, multifunction input alarm delay (code
“iA”)
if i5 and/or i15 = 3, delay in compressor switching on
after the deactivation of the multifunction input (34)
