EVCO S.p.A. EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 71 of 100
PARAM. MIN. MAX. M.U.
EVB1204 EVB1214 EVB1206 EVB1216 EVB1226 EVB1236 EVB1246 EVB1256
DIGITAL OUTPUTS
u1 0 12 - - - - 0 0
not
avail.
not
avail.
not
avail.
not
avail.
not
avail.
not
avail.
operation controlled by digital output K4 (35) (36)
0 = ROOM LIGHT - in this case the “AUXILIARY” key
and parameters i0 and u2 will be activated
1 = DEMISTER HEATING ELEMENTS - in this case the
“AUXILIARY” key and parameter u6 will be
activated
2 = AUXILIARY OUTPUT - in this case the “AUXILIARY”
key and parameters i5, i15 and u2 will be
activated
3 = ALARM OUTPUTS - in this case parameter u4 will
be activated
4 = DOOR HEATING ELEMENTS - in this case
parameter u5 will be activated
5 = HEATING ELEMENTS FOR NEUTRAL AREA
OPERATION - in this case parameter u7 will be
activated
6 = CONDENSER FAN - in this case parameters P4,
F11 and F12 will be activated
7 = COMPRESSOR 2 - in this case, parameters r0,
r12, C11, C12 and C13 (37) will assume
significance of
8 = DEFROSTING 2 - in this case parameters P4 and d
(38) will assume significance
9 = EVAPORATOR FAN 2 - in this case parameters P4
and F (39) will assume significance of
10 = PUMP DOWN VALVE - in this case parameters
C14 and u3 will assume significance of
11 = ON/STAND-BY - in this case “ON/STAND-BY” key
will assume significance (42)
12 = MAN IN COLD ROOM - in this case parameters i5
and i15 will assume significance of
