4
Pre-Installation
APPLICATION
This unit is a single stage jet pump designed for shallow water well applications, where the water level is less than 25 ft. deep. If the water
level to the pump is deeper than 25 ft. a convertible jet pump or a deep well submersible pump should be used. A pressure switch pre-set
at 30 Psi "on", 50 Psi "off" has been installed on the pump. The pressure switch will automatically turn the pump on and off based on the
system pressure.
TOOLS REQUIRED
Flathead
Screwdriver
Phillips
Screwdriver
Wrench
PVC
PVC
Cement
Safety
goggles
Tape
Measure
Thread
Tape
PVC
PVC
Primer
PACKAGE CONTENTS
A
CC
B
SKU #1011677533, 1011677534
Part Description Quantity
A Pump 1
C Pressure Gauge 1
SKU #1011677535, 1011677537
Part Description Quantity
B Pump 1
C Pressure Gauge 1
