Exterior Equipment
To use the table, remove the table from the cockpit
sole or shing deck and set it on the rear of one
of the bow seats. Remove the table pedestal from
the storage compartment. Pull the safety pin in
the side of the mounting bracket and insert the
pedestal base rmly in the bracket, then release
the pin and make sure it extends into the pedestal
base to secure the pedestal to the base. Then in-
stall the table on the pedestal. Reverse the process
to remove the table.
The table should only be used while running at
slow speeds, at the dock or at anchor. Always
remove and properly stow the table and pedestal
before operating the boat above slow speed. This
is particularly important when the boat is being
run oshore.
Forward Below Deck Fishbox
An insulated shbox is located below the cockpit
sole, just forward of the console seats. The hatch
is equipped with gas charged springs that hold
it in the open position. A ush, twist lock latch
secures the hatch in the closed position. Always
make sure the hatch is closed with the latch in
the secured position before operating the boat
above idle speed.
The shbox is drained by a macerator pump in the
head compartment bilge activated by a switch in
the helm switch panel or touch screen display. Be
sure to monitor the water level in the shbox and
turn the pump o as soon as pumping is complete.
The pump will be damaged if it is allowed to run
dry for more than a few seconds. The shbox
should be pumped out and cleaned after each use.
Refer to the Drainage Systems chapter for more
information on the shbox drainage.
Drain rails around the hatch are equipped with
drains that are connected to thru-hull ttings in
the hull.
Forward Fishbox Drain & Drain Rails
Table Mounting Bracket & Safety Pin
