VENTILATION SYSTEM
10.1 Head Compartment Ventilation
Head Compartment Door
Ventilation to the head compartment is provided
by opening the door and a window. The door is
held in the open position by an automatic mag-
netic latch. Make sure the door is fully latched
in the closed position before operating the boat
above idle speed.
Port Window
An opening port window is located on the star-
board side of the head compartment. It is
equipped with a screen and secured in the closed
position by three twist action locks. The locks
should be adjusted so they are tight enough to
seal the window in the closed position, but not so
tight that they break the plastic.
Always make sure the window is closed and se-
cured with the cam levers whenever the boat is
underway. Sea spray could enter the compart-
ment through an open window and damage equip-
ment or items stowed there.
Chapter 10:
Head Compartment Door
Typical Cabin Port Window
