Optional conguration 2 (Enigma | Shotmaster)
• For more information, connect to the e'Support center (https://support.eversys.com/hc/en-us)
and search for PI-31 Device socket(s) (C13 plug) on Enigma and Shotmaster.
3
2
1
(1) 2 x Device sockets (C13 plug) (3) 1 x Ethernet connection
(2) 1 x CCI | CSI | API connection
Optional conguration 3 (Enigma E'4s | E'4ms | E'4s x-wide | E'4ms x-wide)
• For more information, connect to the e'Support center (https://support.eversys.com/hc/en-us)
and search for PI-31 Device socket(s) (C13 plug) on Enigma and Shotmaster.
3 2
1
(1) 1 x Device socket (C13 plug) (3) 1 x CCI | CSI | API Double connection (API
only single)
(2) 1 x Ethernet connection
Options
