EVERVOLT EVHB-I7 - Page 19

16 inch wood studs
Wood Studs (spaced at 16 and 32 inches)
If anchoring directly into wood studs, use at least 8 screws with washers
respectively for inverter and battery, of sufficient length into the studs.
Scheme B
Mechanical InstallationMechanical Installation
33
32
32 inch wood studs
