20 inch wood studs
Wood Studs (spaced at 20 inches)
If anchoring directly into wood studs, use at least 8 screws with washers
respectively for inverter and battery, of sufficient length into the studs.
Scheme C
Mechanical InstallationMechanical Installation
35
34
28 inch wood studs
Wood Studs (spaced at 28 inches)
If anchoring directly into wood studs, use at least 8 screws with washers
respectively for inverter and battery, of sufficient length into the studs.
Scheme D
