IONPURE
®
MX CEDI Modules
Page 10 of 32 IP-MAN-MX-Rev E
2.4.2 Space Requirements
The physical dimensions of the MX Module are given in section A.2 In addition to the
size of the module itself, the site-specific arrangement of the piping and electrical
connections determines the amount of space the module needs to operate.
2.4.3 Electrical Requirements
The MX module requires the following power sources. In all cases the cathode must be
at ground potential.
Table 2-1. Electrical requirements for the MX Modules *
Model Nominal Flow Rate DC Power
MX30 30 LPH 0 - 27 VDC, 0 - 2.5 Amps
MX60 60 LPH 0 - 53 VDC, 0 - 2.5 Amps
MX125 125 LPH 0 - 106 VDC, 0 - 2.5 Amps
MX250 250 LPH 0 - 213 VDC, 0 – 2.5 Amps
MX500 500 LPH 0 - 426 VDC, 0 - 2.5 Amps
* Depends on application, calculate using IP-PRO projection tool
2.4.4 Feed Water Requirements
Feed water for the MX module must always meet the requirements outlined in Table 2-2.
Table 2-2. Feed Water Requirements for the MX Modules
Parameter Specification
Feed water type RO permeate
Feed conductivity equivalent ≤ 40 µS/cm
Silica ≤ 1 ppm as SiO
2
Iron, manganese, sulfide ≤ 0.01 ppm
Total chlorine ≤ 0.02 ppm as Cl
2
Total hardness ≤ 1.0 ppm as CaCO
3
Total organic carbon (TOC) ≤ 0.5 ppm as C
Operating pH range 4 - 11
Operating temperature 41 – 113°F (5 – 45°C)
Inlet pressure ≤ 75 psi (5 bar)
