IONPURE
®
MX CEDI Modules
Page 9 of 32 IP-MAN-MX-Rev E
2. PRE-INSTALLATION: PREPARATION & REQUIREMENTS
2.1. Tools and Equipment
The following items are required to unpack, position, and install the MX module:
• Slip joint pliers (to tighten plumbing fittings).
• Wire cutters/strippers (to prepare wires for DC power connections).
• Phillips head screwdriver (to remove junction box cover).
2.2. Electrical and Plumbing Connection Requirements
• The amounts, sizes, and types of these supplies will vary based upon system size.
Check beforehand to determine the system needs.
• Conduit, wires and appropriate conduit connectors to run the DC power and ground
from the DC power controller to the module. The module includes a terminal ring for
14-16 AWG wire. It is always important to size wire in accordance with local electrical
code.
• Use non-metallic, 3/8” BSPTM adapter fittings (not supplied with module) to connect
ports on the module to the system plumbing.
• To avoid the risk of electrical shock, some form of grounding must
be used on any stream where there is metallic plumbing or
accessories (such as sample ports or instrumentation) in close
proximity to the module.
2.3. Inspect the Module
Do not uncrate the module prior to moving it into its final location. After uncrating it,
inspect it for any signs of damage. If damage is apparent, immediately notify your Local
Service Provider and the carrier.
2.4. Operating Requirements
In order to operate to specification, the MX module must have the following conditions
present. If any of these conditions are unmet, do not attempt to install the MX module
without specific instructions from your Local Service Provider Technical Support.
2.4.1 Operating Environment
The MX module requires indoor installation out of direct sunlight. The
maximum ambient room temperature should not exceed 113 °F (45° C).
The module can tolerate humidity of up to 90%, as long as condensation
does not occur.
