Page 31 IP-MAN-MX-Rev E
APPENDIX A: IP-MX MODULE SPECIFICATIONS
Table A-1 IP-MX Module Dimensions and Weights
IP-MX30 IP-MX60 IP-MX125 IP-MX250 IP-MX500
Diameter, in (cm) 7.0 (17.78) 7.0 (17.78) 7.0 (17.78) 7.0 (17.78) 7.0 (17.78)
Length, in (cm) 7.25 (18.41) 8.83 (21.27) 10.77 (27.37) 15.45 (39.23) 24.79 (62.9)
Operating weight, lbs (kg) 10 (4.5) 13 (5.9) 23 (10.45) 31 (14.09) 47 (21.36)
Shipping weight, lbs (kg) 12 (5.4) 16 (6.8) 21 (9.55) 28 (12.73) 43 (19.55)
MX Module Product Flow Rates and Pressure Drops
Module IP-MX30 IP-MX60 IP-MX125 IP-MX250 IP-MX500 ΔP
LPM (GPM) LPM (GPM) LPM (GPM) LPM (GPM) LPM (GPM) PSID (BAR)
Minimum flow
0.25 (0.06) 0.5 (0.13) 1.05 (0.27) 2.1 (.55) 4.15 (1.1) 5-10 (0.3-0.7)
Nominal flow
0.5 (0.13) 1.0 (0.26) 2.1 (0.55) 4.2 (1.1) 8.3 (2.2) 10-20 (0.9-1.5)
Maximum flow
0.75 (0.19) 1.5 (0.39) 3.15 (0.8) 6.3 (1.62) 12.45 (3.3) 30-40 (1.8-2.8)
Recovery:
85-95 %
NOTE: 95% recovery requires ion exchange softening or 2 pass RO.
For 95% recovery, feed hardness must be ≤ 0.2 ppm as CaCO
3
and feed silica must be
≤ 0.5 ppm as SiO
2
To Next Page
