IONPURE
®
MX CEDI Modules
Page 13 of 32 IP-MAN-MX-Rev E
3.3. Electrical Connections
3.3.1 General guidelines
• Do not run AC and DC wiring within the same conduit. This may cause interference
and lead to malfunctions.
• Connect wires to module first before connecting to DC power supply.
• Make sure that DC power supply is de-energized before opening its
enclosure and follow accepted Lockout/Tagout procedures when
working on the system.
• All wiring done in the field must conform to local electrical codes. Consult your Local
Service Provider if there is a conflict between the instructions in this manual and the
local codes.
3.3.2 Module connections
• Connect wire rated for 2.5 amps to MX module anode (+) post. Connect other end of
wire to power supply DC positive (+) terminal.
• Connect wire rated for 2.5 amps to MX module cathode (-) post. Connect other end
of wire to power supply DC negative (-) terminal.
• Ensure that polarity of DC connections is correct before applying
DC power. Operation with polarity reversed will permanently
damage the cathode.
