1-3 POWER SOURCES
Applicable Power Sources
1. AC 115V ± 10%
2. AC 230V ± 10%
3. 6V/1.2Ah Rechargeable battery
4. 6V/4Ah Rechargeable battery
5. 6V/10Ah Rechargeable battery
6. 9V DC via mains adapter
Power Consumption
Approximately DC 20 mA
Approximately DC 40 mA (With display Backlight)
Low Power Warning
When the symbol is displayed, it indicates that the scale needs to be
recharged or the dry batteries need to be replaced.
If the scale is not recharged after the low battery symbol is displayed, the scale will
switch itself off after 20-30 minuets.
4 Red light: Scale needs to be recharged.
Green light: Scale is recharged.
