EXCELL PRECISION CO., LTD.
Counting ZSME200000003
10
CHAPTER 2 OPERATION
2-1 SWITCH SCALE ON
To switch on the scale, ensure that the weigh pan is empty and press the ON/OFF
switch towards the (“ | ”) position and the scale will power on and set zero ready for
weighing or counting operations.
4 If the scale has a RS232 option fitted, the interface card number will be displayed
during the power up sequence.
2-2 SWITCH SCALE OFF
To switch the scale off, press the ON/OFF switch towards the (“ ¡ ”) position.
2-3 DISPLAY BACKLIGHT
AUTO BACKLIGHT
Press
Z
key, the unit weight displays followed by pressing
5
When the weight is over 10 divisions or any key is pressed, the display backlight
will be switched on. When the weight returns to zero or the weight on platform is
less than 10 divisions, the display backlight will switch off after 5 seconds.
BACKLIGHT ON
Press
Z
key, the unit weight displays followed by pressing
4
Backlight is on all the time.
BACKLIGHT OFF
Press
Z
key, the unit weight displays followed be pressing
6
Backlight is off.
4 The backlight mode is stored in memory and will restored when the scale is
switched off and back on again.
