EX-2001 NC RACER ZSME300000091

EXCELL PRECISION CO., LTD.

DATA IN / OUT

LOAD CELL

FUSE/0.5A

AC 100V~240V

CONTROL IN / OUTPUT

2 1

C2 C1

4 3 2 1

OUTPUT

INPUT

before opening the covers.

Isolating the ac power

! WARNING

4 CAPACITY PARAMETER & CALIBRATION SWITCH

Slide the switch to the left is “ON” and Slide the switch to the right is “OFF”

3-2 REAR PANEL

1. AC power in terminal

2. Fuse 250 V / 0.5 A

3. Load cell connector

4. Optional interface location (if fitted)

5. Control I/O Interface location
