Excell NC RACER EX-2001 User Manual

EX-2001 NC RACER ZSME300000091
5
EXCELL PRECISION CO., LTD.
CHAPTER 1 OPERATION GUIDE
FUNCTION OPERATION PROCEDURE DESCRIPTION
General function
setting
Press and hold the key,
then press the
Refer to Chapter 9 Functions Table
to set FUNC. 0 ~ FUNC. 7
Capacity parameter
setting
Switch the capacity calibration
switch to “ON”
and then press the
Set the parameter for decimal
point, max. capacity, min. division,
zero tracking, unstable detection
Refer to < 5-1 > Parameter Setting
Calibration
Switch the capacity calibration
switch to “ON”
and then press the
Calibration procedures.
Refer to < 5-2 > Calibration Setting
Self-diagnosis mode
Turn on the indicator,
press and hold and
the indicator starts the self-test
procedure.
Refer to < 8-3 > Self-diagnosis
Mode for details
Reset all parameters
back to default
Switch the calibration switch to
“ON”, turn on the indicator,
press and hold and
while the indicator is in the
self-testing sequence
Refer to < 8-1 > Reset All
Parameter Back to Default
Reset general function
parameter back to
factory standard setting
Turn on the indicator,
press and hold , followed
by pressing
while the indicator is in the
self-testing sequence
Refer to < 8-2 > Reset General
Function Parameter Back to
Default
Display software version
Turn on the indicator,
press and hold the
while the indicator is in the
self-test sequence
The main display section displays
the software version, press any key
to exit
Function parameter
setting
Press and hold ,
followed by pressing
HI, LO, Zero Band parameter
setting
ENTER
F n
F n
C A L
ENTER
GROSS
NET
F n
ENTER
F n
ENTER
C A L
ENTER
C A L
