Excell NC RACER EX-2001 - 7-5 OP-06 RS-232 & CURRENT LOOP; RS-232; Current Loop Operation

EX-2001 NC RACER ZSME300000091
32
EXCELL PRECISION CO., LTD.
FG
RxD
TxD
SG
+ AC
- AC
C.LOOP
C.LOOP
1
2
3
4
5
7
12
13
CONNECTION
7-5 OP-06 RS-232 & CURRENT LOOP
2
RS-232 / CURRENT LOOP
RS-232C is a bi-directional output/input; CURRENT LOOP is one-way output only,
and the output data format is the same as RS-232.
FG
RxD
TxD
SG
+ AC
- AC
C
.
LOOP
C. LOOP
1
2
3
4
5
7
12
13
接線圖
2 Refer to Chapter 9 Functions Table to set FUNC 60 ~ FUNC 69
CONNECTION
